Capacitor Discharge Spot Welding Machine Series(Single-Head)

电容储能式点焊机系列（单头）

产品概述

电容储能点焊机利用电容储存能量，当能量使小面积焊点熔化时，电容瞬时放电。与其它焊接方式如交流机相比，从电网取用瞬时功率低，各相负载均衡，功率因素高，且可向焊接区提供集中能量，能得到表面质量好的难焊有色金属。适合于焊铝，铜银、镍金属及合金材料的焊接。该焊接方法已大量用于工业生产，如五金、家电，电子，金属器皿等行业。

Description

Capacitor discharge spot welder uses capacitor to store energy and to release instantaneous current.ln the meantime,it concentrates large current to pass through a small point and then achieves welding effect.Compared with the common AC machine with the same capability,this machine gets low surge power from the power grid and the power factor is high.Therefore,it can minimize the situation that the work piece being deformed and get good looking welding surface.lt can welding some conductive and nonferrous metals,can be used to welding metals like aluminum,copper,silver,nickel and alloy.This welding method has been widely applied to industries manufacturing such as hardware,electronic,metal ware etc.

性能特点

1可焊接达8mm不锈钢、铜、铝、钛等有色金属。

2焊接牢固，焊点无发黑，省去打磨工序。

3内部电源稳压装置，保证输出电压恒定，焊接一致性好。

4世界名厂元器件，性能稳定可靠。

5设计操作简单，免除复杂调校程序。

Features

1. Be able to weld 8mm of　nonferrous　ｍetals like stainless steel,aluminum,titanium,silver,etc.

2. Firm welding;No black coating on the welding spots so no polishing process is needed.

3. Equipped with internal power supply voltage stabilizer to ensure constant output voltage and good welding consistency.

4. All the parts are imported from famous brands with ideal service life and performance.

5. Simple operation,avoid complicated testing program.

适用范围

特别适用于电器、表带、首饰、不锈钢餐具及各类五金制品等厂家使用。

Application

Especially suitable for manufacturing electric appliance,watchband,jewelry,stainless steel cookware,etc

WL-C-2K       WL-C-2K            WL-C-3K.

apacitor Discharge Spot Welding Machine Series(Single-Head)

电容储能式点焊机系列（单头）

WL-C-5K              WL-C-10K            WL-C-18K

WL-C-20K              WL-C-25K           WL-C-40K

WL-C-50K(三工位机头)

电容储能式点焊机外型装配示意图

Capacitor Discharge Spot Welding Machine Exterior Assembly Diagram

电容储能式点焊机系列规格参数

Models and Specifications of All Capacitor Discharge(Single-Head)Spot Welder
